SELF-SERVE
CAR WASH FRAMES

The metal frame is designed of AISI 304 stainless steel, which is considered to be an international food grade stainless steel. The customer can choose from two surface options: glossy (mirror-like) and polished (satin-like). The frame is bolt jointed, which means that all its parts are securely bolted to each other. That allows installation with only three people involved, with the installation capacity of 2 posts per day. A distinctive feature of this particular frame is the drainage system, specially developed by PPM GROUP, the frame system efficiently combines the load-bearing elements and the drainage system itself. We mindfully took into account all possible loads on the unit when selecting load-bearing profiles and elements of the construction.
The outer columns are made of pipe size 100 * 100
Middle column is made of pipe size 80 * 80
The arch elements, made with the pitch, suitable for using cellular polycarbonate as a roofing material, are situated under the roofing.
Post size: width - 5 m. Length - 6 m.
This design will serve forever!

The metal frame is made of metal rolling. Two options of protective layers: powder painting or hot-dip galvanizing. For powder painting we give the customer the choice between two options of surface paint coat: glossy and matte. Any color from the international RAL color catalog is available. The frame is bolt jointed, which means that all its parts are securely bolted to each other. That allows installation with only three people involved, with the installation capacity of 2 posts per day. We mindfully took into account all possible loads on the unit when selecting load-bearing profiles and elements of the construction. The outer columns are made of pipe 100 * 100
Middle column from pipe 80 * 80 Under the roofing, arc elements have been developed and made with the necessary pitch for using cellular polycarbonate as a roofing material. Post size: width - 5 m. Length - 6 m.
This design will serve you at least 10 years.

The metal frame is made of metal rolling. Two options of protective layers: powder painting or hot-dip galvanizing. For powder painting we give the customer the choice between two options of surface paint coat: glossy and matte. Any color from the international RAL color catalog is available. The frame is bolt jointed, which means that all its parts are securely bolted to each other. That allows installation with only three people involved, with the installation capacity of 2 posts per day.
We mindfully took into account all possible loads on the unit when selecting load-bearing profiles and elements of the construction.
Columns are made of pipe 100 * 100
Post size: width - 5 m. Length - 6 m
This design will serve you at least 10 years!

It is made of metal rolling with the protective layer of hot-dip galvanizing. The system is technologically advanced with the ability of installation of banner partitions without the use of eyelets and ropes for pulling the banner canvas on. The cost of the system for one partition is $ 600.
